The A1001 is Times-7’s smallest near-field RFID antenna, delivering precise on-surface reads and seamless integration into compact indoor environments. Optimised for Tap-and-Go.

About

The A1001 is the smallest near-field RFID antenna in the Times-7 product catalogue, with a read range of 0-10cm and UHF wideband frequency coverage. Designed so the radiation intensity peaks right at the antenna's surface, this antenna is the ultimate choice for 'tap and go' applications in indoor environments.

Key Benefits:

  • Small physical footprint for easy integration
  • Perfect for on-surface reads
  • Wideband frequency coverage

This antenna is especially well-suited for use in enclosed spaces and any scenario where a small footprint is essential.

Specifications

Dimensions
82 x 82 x 9.6mm
Frequency Range
Wideband
Polarisation
Near-field
Gain
Near-field - N/A
Beamwidth
Near-field - N/A
Environmental Rating
IP54
Connector Type
SMA

Downloads

A1001_Datasheet
.pdf
507 KB
A1001_Mechanical Drawing
.pdf
92 KB
